Creating custom Revit families can be a game-changer for your BIM projects. Well-designed families improve efficiency, maintain project standards, and enhance collaboration. However, poorly built families can cause slow performance, errors, and confusion. Here are some best practices for custom Revit family creation that every designer should follow.
Value Table: Best Practices for Custom Revit Family Creation
| Best Practice | What It Involves | Value Delivered |
|---|---|---|
| Planning Before Modeling | Defining purpose, parameters, and family type | Saves time, reduces rework |
| Using Reference Planes | Building geometry around reference planes and constraints | Ensures accurate and flexible parametric behavior |
| Lightweight Geometry | Avoiding unnecessary detail and complex forms | Improves model performance |
| Smart Parameter Usage | Correct use of type, instance, and shared parameters | Better control and reliable scheduling |
| Testing in Project Environment | Loading families into real project files | Prevents errors during production |
| Visibility Control | Managing view-specific and detail-level visibility | Cleaner drawings and faster models |
| Consistent Naming Conventions | Clear, standardized naming for families and parameters | Easier library management |
| Documentation & Standards | Maintaining family creation guidelines | Consistency across teams and projects |
| Avoiding Overloaded Families | Creating focused, purpose-driven families | Reduced complexity and fewer errors |
| Continuous Optimization | Updating families with new Revit features | Long-term efficiency and scalability |
1. Plan Before You Build
Before jumping into Revit:
-
Define the purpose: Is it for a specific project or a general library?
-
Know the parameters: What dimensions, materials, or behaviors need to be adjustable?
-
Decide the family type: Choose between system families, loadable families, or in-place families based on your project needs.
Tip: Sketch the object on paper or a software diagram before modeling. It saves time and avoids revisions.
2. Use Reference Planes and Constraints
-
Reference planes are the backbone of parametric families.
-
Apply constraints to ensure your family adjusts properly when dimensions change.
-
Always lock geometry to reference planes to prevent accidental movement.
Pro tip: Name reference planes clearly (e.g., “Center_Plane_X”) for easier management.
3. Keep Families Lightweight
-
Avoid unnecessary detail—complex geometry can slow down your project.
-
Use symbolic lines for 2D representations and simplified 3D geometry.
-
Only include parameters that will be used; too many can confuse users.
Rule of thumb: If an element won’t change or isn’t necessary for construction, keep it out.
4. Use Parameters Wisely
-
Type parameters control all instances of a family type (e.g., standard door widths).
-
Instance parameters allow individual adjustment per instance (e.g., specific window height).
-
Shared parameters are essential if the data will be scheduled across projects.
Tip: Always check parameter names for consistency to avoid confusion in schedules.
5. Test Families in a Project Environment
-
Load your family into a sample project before finalizing.
-
Check how it behaves with other elements, constraints, and schedules.
-
Test both instance and type parameters to ensure flexibility.
Tip: A family that works in isolation but fails in a project can waste hours of work.
6. Use Visibility Settings
-
Control which parts of a family are visible in plan, elevation, or 3D views.
-
Hide unnecessary details in certain views to keep drawings clean.
-
Leverage view-specific detail levels (coarse, medium, fine) to improve performance.
7. Maintain Consistent Naming Conventions
-
Name families, types, and parameters clearly and logically.
-
Example:
Door_SolidCore_900x2100_Woodis better thanDoor1.
-
Consistency helps with library management and avoids confusion in large projects.
8. Document Family Standards
-
Keep a guide or checklist for how families should be created in your office or team.
-
Include rules for naming, parameter usage, geometry modeling, and visibility settings.
-
This ensures uniformity and helps new team members follow the same standards.
9. Avoid Overloading Families
-
Don’t try to make a single family do everything.
-
Multiple specialized families are better than one complex family with dozens of unused parameters.
-
Overloaded families can cause errors and slow down projects.
10. Keep Learning and Updating
-
Revit constantly updates with new features for families.
-
Learn about formulas, nested families, and adaptive components.
-
Review existing families periodically to optimize them for new projects.
Conclusion
Custom Revit families are a powerful tool for creating accurate, flexible, and efficient BIM projects. By planning, using constraints, keeping geometry simple, testing, and maintaining consistency, you can build families that save time, reduce errors, and enhance collaboration.
Remember: a well-built family today prevents headaches tomorrow.
